Well, as I look back over what I've drafted up here, I guess I got a little carried away but here's a list of the things I typically do when accurizing a barrel. First off, a short pre-flight inspection:Before you start removing metalI like to start by giving the barrel an inspection to get an idea of what I'm working with:slug the barrel and feel for issues - Push a pellet through the barrel, from breech to muzzle. We're looking for possible issues in 4 areas:barrel port - pneumatic rifles only (not springers)leade->bore transitionborecrownFirstly, note whether the pellet felt as though it snagged as it went over the barrel port. Most inexpensive factory barrels have not been deburred. Next up is the transition from the leade to the bore. Often there is a sharp edge where the leade necks down to the bore. Here, the sharp edge at the beginning of the rifling will tend to smear the head and skirt. Continuing on, note any loose or tight spots along the barrel's length. What I'm wanting is a pretty consistent, light resistance all the way through...that is, unless the muzzle is choked. Lastly, pay close attention to resistance just as the head and skirt pass over the crown and emerge into the outside world. Hanging up here is an indication of a burr left after crowning that will need to be dealt with. BTW, distinguishing between a choked barrel and a burr at the crown normally is fairly easy. In a choked barrel you'll encounter resistance for the last inch or two. If the crown is defective, you'll hit a snag just as the pellet comes out the end.inspect the pellet - Now inspect the pellet(s) with the help of some magnification. Damage in a confined spot around the perimeter of the skirt usually indicates a burr at the barrel port. Smearing of the skirt where it met the rifling usually indicates a sharp edge at the leade->bore transition. Slight rifling marks around the head are a good indication that the pellet is a good fit for the barrel...enough to prevent yawing as it hurtles down the bore but not so much that it damages the head. By contrast, rifling engagement of the skirt should be deeper because the skirt is a larger diameter by a few thousandths. Now with some expectation of what you have to deal with, on with the barrel treatments...Down to businessdeburr the barrel port - Use a small diamond ball grinder to radius the edges of the barrel port. What I do is load a 3/32" (for .177 cal) or 1/8" (for .22 cal or larger) diameter ball into the Dremel running at its lowest speed, and work it from inside the hole and up over the sharp edge all the way around the perimeter of the hole. Don't go crazy with it; the radius need only be ten or fifteen thousandths (0.010" - 0.015"). Just trying to get rid of the wire edge left from the drilling operation. Then take a small dowel or skewer wrapped in 320 then 400 grit to polish the newly-formed radius. Apply some light oil (mineral oil, WD40, etc.) to help shed the swarf. Since this work is done at a shallow angle, round over the end of the dowel so it can dip into the hole as you pass it back and forth. Expect to chew up the paper a couple of times; just keep refreshing the abrasive and work it until it is smooth. It will become apparent when you've done enough because the paper will no longer be as apt to shred.treat the leade->bore transition - A picture is in order: (thanks to Kirby)Knock down the sharp transition between the leade and the bore. A regimen of 320, 400, and 600 grit is good for this operation. Wrap the paper around a small dowel and sweep it in and out, applying pressure all around the perimeter. polish the bore - The pros swear by this. I've only done it a handful of times and I haven't formed a strong opinion about it yet. It does seem to improve precision a bit and will extend cleaning intervals (lead will not abrade and stick to the walls as readily). Some claim it also makes a barrel less pellet fussy; I don't doubt it but I haven't noticed it in my limited experience. Things you will need:cleaning rod - Critical that it be a good double ball bearing cleaning rod to ensure the cleaning pellet/wad/patch follows the riflingsrod adapter - Brownell's VFG stuff is recommended for .22 cal and above. Specifically, the 084-000-002WB adapter. For .177, use a good jag and cotton patches.cleaning pellets - firm felt pellets for Brownell's VFG system such as part number 610 for .22 cal.abrasive - A fine friable abrasive like J-B Bore Paste seems to be the most recommended but folks have successfully used stuff like Flitz metal polish or rottenstone.lubricant - Kano Kroil seems to be preferred but another light oil can be substituted. Its role is to help float away the swarf.See these two excellent threads for more information, in particular the guidance offered by Motorhead and SeanMP:J-B bore pasteDeburring riflings - JB Bore Pastetouch up the crown - Firstly, there are many different geometries that can be applied to a crown but most air rifle barrels will have a simple chamfer so that's what I will focus on. Give the crown a closeup visual inspection. If the chamfer is a uniform width all the way around the perimeter, a little touchup with a brass screw will do. What you will need is a round head (not pan head) brass screw. #6 is good for .177 cal and a #8 is good for .22 and .25 cal. Whereas most everything that has been discussed thus far should be done with the barrel removed, you can do this procedure with the barrel installed. Secure the barrel in an upright position so you can have both hands free. Stuff a small piece of cotton into the muzzle to keep debris from falling down into the barrel. Chuck up the screw into a handheld drill. Coat the head of the screw in polishing compound and press it against the muzzle and operate the drill at low speed, moving it in an irregular circular pattern. I use the term "pattern" loosely; you expressly want to randomize the movements. If you try to hold the drill in one position, invariably more pressure will be applied to one side which will abrade an irregular bevel into the crown. Afterwards, very gently drag a cotton swab across the crown and see if it snags. If it does, you still have a burr that needs to be worked down. A good crown will also have a distinct cog-like appearance when viewed under magnification, owing this to sharp, burr-free lands and grooves.If the chamfer is irregular, the end of the barrel will need to be reworked. If you can have someone with a lathe do it for you, that is probably best for most weekend warriors but if you are confident in your abilities, you can chop and recrown on your own. Here is a link to my DIY crowning guide using a drill press to achieve a perfectly square crown without a lathe. There are many different ways to go about it and some good videos can be found by searching youtube. Checking your workAfter all the work has been completed, I like to use compressed air to blow away any loose and/or heavy debris, then run a few cleaning patches through the barrel. Then I slug the barrel again, looking for any remaining trouble spots. If all looks good, back on the gun it goes and then off to shoot groups with various pellets to see what the gun likes.
